RAMI AV-601 Radar Antenna

$347.60/Each
Price Includes GST
Quantity
Add to Wishlist
Part# 11-16527
MFR Model# AV-601

Overview

The AV-601 antenna is designed specifically to meet FAA TSO-C87a specifications. Qualification testing includes meeting the requirements of EUROCAE ED-30, Edition 2, “Minimum Performance Standards for Airborne Low Range Radar Altimeter Equipment”, as modified by Appendix 1 of the TSO.

Specifications

  • Application: Airborne Low Range Radar Altimter
  • Frequency: 4200-4400 MHz
  • Impedance: 50 Ohms
  • VSWR: 1.5:1 Max (4275-4325 MHz) / 2.3:1 Max (4200-4400 MHz)
  • Polarization: Linear
  • Pattern: Roll Plane(E): 45° min.
  • Beam Widths: Pitch Plane (H): 40° min.
  • Connector: TNC Female
  • Max Height: .14″
  • RF Power Capacity: 5 watts avg./500 watts max.
  • FAA TSO: C87a
