Manifold Pressure Sensor A200-Pmp
MFR Model# A200-PMP
Overview
|
The A200-PMP is a bulk micro-machined, absolute type pressure sensor for use in both harsh and benign media with superior accuracy over an operating temperature of -40°C to 105°C. It has superb accuracy of +/- 0.5% full scale. It contains a custom ASIC which provides signal conditioning for calibration and temperature compensation at the point of measurement. Each sensor is traceable to NIST calibration standards. Supplied with a 36" color coded cable. |
Specifications
- Power requirements are 5V / 10mA
- Signal output is linear and varies from 0.5V (0 PSI) to 4.5V (100 PSI)
- Overpressure burst rating is 300 PSI
Q&A
Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Per the supplier: "No, we do not show this as a direct replacement for Cirrus P/N 12635-001 or 12635-003." We may be able to special order it for you. Please call sales to set up the special order.
