Hat Section .020 2024T3 Aluminum - 8Ft

$40.48/Each
Price Includes GST
Quantity
Add to Wishlist
Part# 03-46500

Overview

Fabricated from .020 2024T3 aluminum. Wt. 5 oz. per 8-ft. length. May be spliced to form longer stringers.

If mfg test reports are required there is an additional charge per order. Charge is higher if more than 5 items. Certs must be requested at time of order.

Reviews

Q&A

Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Hi, I'm interested in part number 03-46500. Can you cut the item into 4 foot pieces for shipping? Regards Mirko Mattesini

Yes, we can cut into smaller pieces for shipping. Must purchase complete 8 foot pieces and cut down. Please add cutting instructions to the "Special Instructions" box at the Shopping Cart screen at time of order.

Q: Could you please provide the dimensions for this 2024T3 hat section?

The dimensions are: 1/4" Height x 1-1/2" Width x 8 ft Length x .020 thickness.

Q: Are there particular splices to use with these hat sections, or can a piece of the hat section be cut and used as a splice?

We do not know of a specific splice for these but you could likely use a cut piece of the stringer as a splice to join two pieces.
