Metal Jacket For Odyssey 680 Amp Battery
$24.75/Each
Price Includes GST
Part# 11-02234
MFR Model# RED
MFR Model# RED
Overview
| Metal Jacket (Tray) for Odyssey 680 Amp battery |
Specifications
| MODEL | Volt | PHCA** 5 sec | CCA* | HCA | MCA | Nominal Capacity | Res Cap Min. | Length In. (mm) | Width In. (mm) | Height In. (mm) | Weight lbs (kg) | Terminal | Torque Spec lbs (max) | Internal Res (mΩ) | Short Circuit Current | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 20HrAh | 10HrAh | |||||||||||||||
PC310 | 12 | 310 | 100 | 200 | 155 | 8 | 7 | 9 | 5.43 (138.0) | 3.39 (86.0) | 3.98 (101.0) | 5.9 (2.7) | M4 - Receptacle | 8.9 (1.0) | 27.1 | 455A |
PC370 | 12 | 425 | 200 | 315 | 270 | 15 | 14 | 25 | 7.9 (200.0) | 3.0 (77.0) | 5.5 (140.0) | 12.5 (5.7) | M6 Stud | 35 (3.9) | 13.5 | 891A |
PC535 | 12 | 535 | 200 | 300 | 265 | 14 | 13 | 21 | 6.70 (170.2) | 3.90 (99.1) | 6.24 (158.5) | 12.0 (5.4) | M6 - Receptacle | 40 (4.5) | 8 | 1000A |
PC545 | 12 | 460 | 150 | 280 | 220 | 13 | 12 | 18 | 7.00 (177.8) | 3.38 (85.9) | 5.17 (131.3) | 11.4 (5.2) | M6 - Receptacle | 50 (5.6) | 10 | 1200A |
PC625 | 12 | 540 | 220 | 420 | 340 | 18 | 17 | 26 | 6.70 (170.2) | 3.90 (99.1) | 6.95 (176.5) | 13.2 (6.0) | M6 - Receptacle | 40 (4.5) | 7 | 1800A |
| PC680 | 12 | 520 | 170 | 350 | 280 | 16 | 16 | 24 | 7.27 (184.7) | 3.11 (79.0) | 7.55 (191.8) | 15.4 (7.0) | M6 - Receptacle or SAE 3/8 Receptacle | 50 (5.6) | 7 | 1800A |
PC925 | 12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.64 (168.7) | 7.05 (179.1) | 5.83 (148.1) | 26.0 (11.8) | M6 - Receptacle or SAE 3/8 Receptacle | 60 (6.8) | 5 | 2400A |
PC950 | 12 | 950 | 400 | 600 | 500 | 34 | 32 | 60 | 9.8 (250.0) | 3.8 (97.0) | 6.1 (156.0) | 20.0 (9.0) | M6 Stud | 35 (3.9) | 7.1 | 1700A |
PC1100 | 12 | 1100 | 500 | 800 | 650 | 45 | 43 | 87 | 9.8 (250.0) | 3.8 (97.0) | 8.1 (206.0) | 27.5 (12.5) | M6 Stud | 35 (3.9) | 5.1 | 2450A |
PC1200 | 12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.87 (199.9) | 6.66 (169.2) | 7.60 (193.0) | 38.2 (17.4) | M6 - Receptacle or SAE 3/8 Receptacle | 60 (6.8) | 4.5 | 2600A |
PC1220 | 12 | 1220 | 680 | 960 | 860 | 70 | 64.8 | 135 | 10.94 (278.0) | 6.88 (175.0) | 7.48 (190.0) | 45.6 (20.7) | DIN Lead Post | N/A | 5.7 | 2200A |
75-PC1230 | 12 | 1230 | 760 | 1050 | 815 | 55 | 50 | 110 | 9.46 (240.3) | 7.08 (179.8) | 7.22 (183.4) | 45.5 (20.6) | SIDE 3/8 Receptacle | 60 (6.8) | 2.5 | 3100A |
75/86-PC1230 | 12 | 1230 | 760 | 1050 | 815 | 55 | 50 | 100 | 9.46 (240.3) | 7.08 (179.8) | 7.92 (201.2) | 45.5 (20.6) | Top SAE SIDE 3/8 Receptacle | 60 (6.8) | 2.5 | 3100A |
PC1350 | 12 | 1350 | 850 | 1080 | 960 | 95 | 88.5 | 195 | 13.90 (353.0) | 6.88 (175.0) | 7.48 (190.0) | 60.4 (27.4) | DIN Lead Post | N/A | 4.2 | 2900A |
25-PC1400 | 12 | 1400 | 850 | 1150 | 950 | 65 | 55 | 130 | 9.46 (240.3) | 6.84 (173.7) | 8.69 (220.7) | 50.0 (22.7) | SAE | 60 (6.8) | 2.5 | 3100A |
35-PC1400 | 12 | 1400 | 850 | 1150 | 950 | 65 | 55 | 130 | 9.46 (240.3) | 6.84 (173.7) | 8.69 (220.7) | 50.0 (22.7) | SAE | 60 (6.8) | 2.5 | 3100A |
34-PC1500 | 12 | 1500 | 850 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) | 6.76 (171.7) | 7.88 (200.2) | 49.5 (22.4) | SAE | 60 (6.8) | 2.5 | 3100A |
34R-PC1500 | 12 | 1500 | 850 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) | 6.76 (171.7) | 7.88 (200.2) | 49.5 (22.4) | SAE, Positive Right Terminal | 60 (6.8) | 2.5 | 3100A |
34M-PC1500 | 12 | 1500 | 850 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) | 6.76 (171.7) | 7.95 (201.9) | 49.5 (22.4) | SAE - and 3/8 Stud (Pos.) 5/16 Stud (Neg.) | 60 (6.8) | 2.5 | 3100A |
34/78-PC1500 | 12 | 1500 | 850 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) | 7.08 (179.8) | 7.88 (200.2) | 49.5 (22.4) | TOP SAE SIDE 3/8 Receptacle | 60 (6.8) | 2.5 | 3100A |
78-PC1500 | 12 | 1500 | 850 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) | 7.08 (179.8) | 7.34 (186.4) | 49.5 (22.4) | SIDE 3/8 Receptacle | 60 (6.8) | 2.5 | 3100A |
PC1700 | 12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.03 (331.0) | 6.63 (168.4) | 7.78 (197.6) | 60.9 (27.6) | M6 Receptacle or SAE 3/8 Receptacle | 60 (6.8) | 3.5 | 3500A |
65-PC1750 | 12 | 1750 | 950 | 1350 | 1070 | 74 | 65 | 145 | 11.83 (300.5) | 7.20 (182.9) | 7.50 (190.5) | 58.0 (26.3) | SAE | 60 (6.8) | 2.0 | 5000A |
PC1800-FT | 12 | 1800 | 1300 | 1600 | 1450 | 214 | 190 | 475 | 22.75 (577.9) | 4.9 (125.0) | 12.44 (316.0) | 132.3 (60.0) | 3/8" Stud | 80 (9.0) | 3.3 | 3800A |
31-PC2150 | 12 | 2150 | 1150 | 1545 | 1370 | 100 | 92 | 205 | 13.06 (331.7) | 6.89 (175.0) | 9.59 (243.6) | 77.8 (35.3) | 3/8" Stud or SAE | 150-220 (16.9-22.6) | 2.2 | 5000A |
31M-PC2150 | 12 | 2150 | 1150 | 1545 | 1370 | 100 | 92 | 205 | 13.00 (330.2) | 6.80 (172.7) | 9.39 (238.5) | 77.8 (35.3) | SAE - and 3/8 Stud (Pos.) 5/16 Stud (Neg.) | 150-220 (16.9- 22.6) | 2.2 | 5000A |
PC2250 | 12 | 2250 | 1225 | 1730 | 1550 | 126 | 114 | 240 | 11.26 (286.0) | 10.59 (269.0) | 9.17 (233.0) | 86.0 (39.0) | SAE Terminal and 3/8" Stud | 100 (11.0) for 3/8" Stud Only | 2.1 | 5000A |
Reviews
As described
Peter W
Verified Purchase
Verified Purchase
Metal Jacket For Odyssey PC680 Red
January 19, 2024
Q&A
Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Q: What is the weight of this metal jacket for Odyssey 680 amp battery?
This product weighs approximately 1.29 lbs.
Q: Is the metal jacket required for the odyssey battery mounting?
Does the Hold Down bracket negate needing the jacket?
The metal jacket is not required for the mounting of the battery. The purpose for the metal jacket is to protect the battery from exposure. The hold down bracket would also protect the battery. This being said, the metal jacket would not be needed if the hold down bracket is in use.
Q: I would like to know the dimensions of the metal jacket.
The Odyssey metal jacket (11-02234) has the following dimensions: Length 7.25", width 3.1", height 6.65"
