PowerUp Bendix Magneto Repair Kit Ab473-R

$273.62/Each
Price Includes GST
Quantity
Add to Wishlist
Part# 07-00855
MFR Model# AB-473R

Overview

These magneto repair kits are designed to simplify the Bendix magneto overhaul process by providing all of the commonly needed overhaul parts in one convenient kit.

The Repair Kits contain the parts needed for minor repair such as a 500 hour inspection.

The Deluxe Repair Kits contain the parts needed for major repair such as a magneto overhaul.

These parts are highest quality direct replacement parts and are approved for installation and use on certificated aircraft. The Repair Kit and Deluxe Repair Kit for the Bendix -200, -201, and -202 series magnetos contain two sets of contact assembly kits. Some parts that may be need replacing during magneto overhaul are not included in these kits.

Magneto No: 10-51360-1 10-51360-3 10-51360-4 10-51360-6 10-51360-8 10-51360-26 10-51360-27 10-51360-28 10-51360-31

Magneto Type: S4R(L)N -20, -21

In The Box

  • Repair Kit
  • 1-CONTACT ASSY. KIT
  • 1-CAPACITOR
  • 2-BEARINGS
  • 1-OIL SEAL
  • 1-OIL SLINGER
  • 3-WOODRUFF KEYS
  • 1-COTTER PIN
  • 1-CAM SCREW
  • 1-FELT WASHER
  • 1-FELT STRIP
  • 1-SNAP RING
  • 1-CARBON BRUSH
  • Component part kits also contain installation hardware
  • Frequently Purchased With
  • Customers Also Viewed

Reviews

Q&A

Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Does this kit also contain bearing grease, gear lube, and oil for the point felt strip? Is the point cam and the bushing in the distributor block lubed?

Kit contains: 1ea) contact assy kit, capacitor, oil seal, oil slinger, cotter pin, cam screw, felt washer, felt strip, snap ring, carbon brush. 2ea) bearings. 3ea)woodruff keys.
