- Photo may represent series and not specific product
- SHARE
Instrument Mounting Nut A8938-632-493
- JUMP TO
- Overview
- Reviews
- Q&A
- View in Catalog
| Obsolete Part No. | Our Part No. | NAS Parts No. | Instrument Thickness |
|---|---|---|---|
| A8938-632-493 | MS33737-9C | 487-13 | .062 |
Overview
|
Cage type. Permit mounting of aircraft instruments from
the front of the panel. No charge in panel or instrument design required. Non-magnetic (speed nut is brass; cage is phosphor bronze). Conform to MIL-N-3336. Cage is easily compressed with finger-pressure to allow insertion of legs into clearance holes. When fully inserted and pressure is released, legs spring apart; retain SPEED NUT in screw-receiving position. Turned down corners hold firm against force of in sert ing screw and screw-tightening torque. All instrument mounting nuts listed below take a 6-32 machine screw. Additional Info: the thread size is the same on each nut, but the instrument bezel thickness can be different per gauge. They are ordered by the back bezel thickness. They are inserted from the back, and they have ears pointing out that slide into a groove between the front and back bezel to stay in place. |
Reviews
Verified Purchase
Instrument Mounting Nut A8938-632-493 (Pack Of 5)
Perfect for making instrument blanks out of 1/16 material.
Verified Purchase
Instrument Mounting Nut A8938-632-493 (Pack Of 5)
Used to make blind nuts when installing instrument cover. Used safety wire between nuts to keep them from spinning.
Verified Purchase
Instrument Mounting Nut A8938-632-493 (Pack Of 5)
Good product good price
Verified Purchase
Instrument Mounting Nut A8938-632-493 (Pack Of 5)
they work.
Pefect for those mounting nuts that fall off in the back of the instrument panel when replacing/removing instruments. Excellent directions and sizing instructions given by AS&S.
OK
I knew what I wanted and that’s what I got.
Great item that can save many hours of frustration compared to trying to thread a traditional nut. Well worth the money.
This type of hardware design is under appreciated. always provides good instrument mounting.
