Poly-Fiber Super Fil

From $42.50 to $353.41
Prices below incude GST
Description Part Number Price Buy
Poly-Fiber SuperFil 1 Qt Kit
(20oz. Resin / 12oz. Hardener)
09-28250
$46.75
Quantity
Poly-Fiber SuperFil 3 Gallon Kit
(2gal. Resin / 1gal. Hardener)
09-28260
$388.75
Quantity
Subtotal $0.00
Add to Wishlist

Overview

An ultra lightweight corrosion-inhibiting filler for aircraft, marine, and automotive use. Adheres to composites, bare aluminum, steel, and bare or varnished wood.

Epoxy resin with non-MDA hardener. Ships non-hazardous. Apply EP-420 Epoxy Primer directly over SuperFil.

Superfil is an ultra-lightweight epoxy filler for rough fill and contouring. Comes in two containers. Mix, apply with a squeegee, and let dry overnight. More consistent than hand-mixed micros. Weighs only 3.8 lbs. per gallon.

1 Quart Kit (12 oz. Hardener + 20 oz. Resin)
3 Gallon Kit (1 gal. Hardener + 2 gal. Resin)

HAZARDOUS

Features

  • Composite Filling:
  • Use as you would an epoxy micro slurry. Mix by the weight for the best results. Scuff-sand smooth surfaces before application. Trowel or squeegee to desired thickness. After drying, sand to shape and finish. Works as an excellent filled material.
  • Bare Aluminum:
  • Scruff surface with a Scotch-Brite pad. Treat bare aluminum with E-2300 Conversion Coating prior to application. Apply EP-420 Primer directly over dried SuperFill.
  • Bare Steel:
  • Clean off all rust and oil, and wipe with C-2200 Meti-Sol.
  • Varnished or Bare Wood:
  • Scuff-sand and clean as necessary. EV-400 Epoxy Varnish may be applied directly over SuperFill.

Specifications

  • By Weight (preferred): 2 parts A to 1 part B
  • By Volume: 2 parts A to 1 part B.
  • Thoroughly stir each individual container of part A and part B before combining. Resin or hardener can separate from fillers during storage. After combining parts A and B scape the sides of the Revision on 21 mixing container to insure a through blend. Mix o a consistent high color blue color.
  • Cure: Allow to cure at 70° or above for best results. Lower temperatures will lengthen the cure time
  • Dry Film Cure: 8 hours at 77°
  • Cure to Sand: 12 hours at 77°
  • Pot Life: One hour at 77°
  • Clean Up: MEK before curing occurs
  • Shelf Life: Twi years unopened. Avoid storage above 100°. Resin will separate from filler during storage. Remix thoroughly.

Reviews

5 star product

Craig L Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

October 8, 2024

An excellent, easily sanded lightweight filler. I began using 3M Glazing putty, but it doesnt sand as well as SuperFil. Also, a very little goes a long way!

Marty T Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

September 11, 2024

Great stuff ! Best filler on the market

Dave P Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

August 28, 2024

As advertised!

Natalie C Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

August 1, 2024

Smells bad but works great! And the sales help was perfect!

Peter S Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

March 29, 2024

I have been using this for several years on R/C model airplanes.

Charles R Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

January 19, 2024

Great product! Unbelievable fast shipping. Always good service with Aircraft Spruce !

Richard K Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

December 6, 2023

Great product, and great service.

C L Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

November 17, 2023

Always a consistent product.

Robert C Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

November 15, 2023

Superfil is my go to product for filler material when strength is needed. It is strong, light and sands well. Its the best filler on the market!

Allen Verified Purchase

Superfil Sandable Non-Shrinking Epoxy Filler Quart Kit

November 2, 2023

Q&A

Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Can you either direct me to, or provide the MSDS for this product please? Cheers, Bruce

We have added the MSDS sheet to the "Documents" tab of this web page. Please review it there.

Q: Does Super-Fil (09-28250) work well on aluminum?

Yes. It is an epoxy base filler and adheres very well to aluminum, wood, and composites.

Q: Will Superfil crack or shrink over long time? Also, what is max depth of fill?

Superfil is an epoxy base material and will not shrink or crack over time like polyester base fillers. The manufacturer does not list a max depth.

Q: Does the filler require a chemical and / or mechanical bond?

This is an epoxy base filler and adheres to many surfaces, but a slightly abraded surface is recommended for the best bond.

Q: You mentioned an abraded surface. I have a well bonded paint, is it necessary to remove the paint and abrade the aluminum or will roughing up the paint surface be sufficient?

No, it is not necessary to remove the paint. Just be aware the Super-Fil will stick to the paint, so if the paint chips off the structure, so will the Super-Fil on it.

Q: Does SuperFil work well on sheet metal?

Yes, It will work on clean metal.

Per Vendor: It can be used as filler on metal, sure, but it should be primed over to seal it.

Q: Can Super Fil be used as a structural adhesive (like regular epoxy) to bond two pieces together?

It is not normally used as an adhesive, so we have no data as to how well it will work.

Q: What is the shelf life for 09-28250 SuperFil Part A & B?

This material has a 2 year shelf life in an un-opened container.

Q: When using in locations which will ultimately be epoxy varnished and fabric covered, should the filler go over or under the varnish?

It should go underneath the varnish. The varnish should seal the superfil.

Q: What can be used to dilute the Super Fil mix so it is not so thick?

Per Poly-Fiber: We do not recommend thinning or diluting this product.
