Lycoming At Overhaul Parts Replacement List - O-235- K L M P
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL61499-1 | 1 | Engine Gasket Set | 08-11792 | $259.55 | |
| SL2351-SC | 4 | Piston Rings | 08-11705 | $183.43 | |
| SL13445 | 4 | Piston Pins | 08-11596 | $95.43 | |
| SL11625 | 8 | Piston Pin Plugs | 08-11530 | $13.53 | |
| SL19034 | 4 | Exhaust Valves | 08-11698 | $368.50 | |
| SL73806 | 8 | Steel Push Rods Assemblies ( 235 & 290’s ) | 08-11914 | $47.85 | |
| SL68763A | 8 | Bearing Inserts ( Main ) | 08-11831 | $48.95 | |
| SL61662 | 8 | Bearing Inserts ( Connecting Rods) | 07-17973 | $40.43 | |
| SL12186 | 8 | Connecting Rod Nuts | 08-11567 | $5.06 | |
| SL-STD-2213 | 1 | Crankshaft Gear Bolt | 08-12039 | $18.15 | |
| SL78531 | 1 | Oil Pump Bodies | 08-12010 | $350.90 | |
| SL18109A-S | 1 | Oil Pump Gears | 08-11683 | $594.00 | |
| SL13792 | 1 | Oil Seal Crankshaft | 08-00292 | $23.87 | |
| SL-STD-208 | 1 | Oil Seal Vacuum Pump | 08-12033 | $11.55 | |
| SL14260 | 1 | Oil Seal Tach Drive | 08-11625 | $5.88 | |
| SL53E19600 | 1 | Thermostatic Bypass Valves | 08-11771 | $389.40 | |
| SL18639 | 1 | Lock Plate Crank Gear | 08-11684 | $2.64 | |
| SL73817 | 2 | Lock Plate Mag Idler | 08-11918 | $2.70 | |
| SL73383 | 1 | Lock Plates | 08-11912 | $4.07 | |
| SL-STD-2180 | 4 | Engine Hoses Oil Drainback Cylinder | 08-00311 | $9.68 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Lycoming engines are the culmination of hundreds of parts improvements made over the last six decades. In Accordance with Textron-Lycoming Mandatory Service Bulletin 240R |
Documents
Reviews
Verified Purchase
Superior SL18639 Lockplate
The correct Part for a 172K. Different than auto hose
Verified Purchase
Superior SlstD2180 Return Hose
Great seals. Have to be a little more careful installing the Superior brand rather than the Lycoming but worth it.
Verified Purchase
Superior Lycoming Crankshaft Seal SL13792
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
installed, works as advertised.
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
It helped with my oil temperature problem. The old one wasnt routing enough oil to the cooler.
Verified Purchase
Superior SL53E19600 Valve, Oil Control, Vernatherm
Very happy you had this in stock. Looks like good quality and I look forward to better seals.
Verified Purchase
Superior Lycoming Crankshaft Seal SL13792
*****
Verified Purchase
Superior Lycoming Crankshaft Seal SL13792
I had to cut the spring as it was too long
Verified Purchase
Superior Lycoming Crankshaft Seal SL13792
As advertized
Verified Purchase
Superior SL2351-Sc Ring Set-Single Cylinder
