Millennium Cylinder Power Assembly Kit Contents SL32006N-A20P For: O-320-B D;IO-320-B (Narrow Deck)
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL72057A + | 1 | Seat, Intake | 08-11875 | $60.45 | |
| SL72058A + | 1 | Seat, Exhaust | 08-11876 | $59.24 | |
| MS20823-8D + | 1 | Elbow | 08-10815 | $33.77 | |
| MS9018-05/2-52 + | 2 | Helicoil | 08-10871 | $13.14 | |
| SL-STD-1872 + | 2 | Helicoil | 08-12032 | $2.50 | |
| MS49005-2 + | 2 | Plug | 08-10863 | $1.71 | |
| SL31C-12 + | 2 | Stud | 08-03636 | $7.15 | |
| SL25C-9 + | 1 | Stud | 08-11713 | $8.25 | |
| SL66610 | 4 | Bushing | 08-11814 | $1.93 | |
| SL32006N-A20P | 1 | Stud Assembly | 08-11732 | $1710.50 | |
| SL13444-1 | 1 | Piston Pin And Plugs | 08-11595 | $115.34 | |
| MS13998-3 | 1 | Cap | 08-10803 | $8.75 | |
| MS13997-3 | 2 | Key | 08-10802 | $7.65 | |
| SL10077 | 1 | Valve Spring Seat | 08-11502 | $13.14 | |
| SL11795 | 2 | Spring | 08-11538 | $14.14 | |
| SL11800 | 2 | Spring | 08-11541 | $17.55 | |
| SL13323 | 1 | Valve Spring Seat | 08-11591 | $14.85 | |
| SL16475 | 1 | Valve Spring Seat | 08-11667 | $19.25 | |
| SL19001A | 1 | Valve, Exhaust | 08-11697 | $327.80 | |
| SL73938 | 1 | Key | 08-11922 | $109.84 | |
| SL65441 | 1 | Spring Seat | 08-11812 | $13.75 | |
| SL12272 | 1 | Lock Plate | 08-11568 | $1.32 | |
| SL71481 | 1 | Cylinder Base Seal | 08-03637 | $3.85 | |
| SL71973 | 1 | Gasket | 08-11872 | $1.38 | |
| SL75906 | 1 | Gasket, Rocker Box | 08-11983 | $2.48 | |
| SL13790A | 1 | Shaft, Rocker | 08-11603 | $28.33 | |
| SL12892 | 2 | Thrust Button | 08-11579 | $4.02 | |
| SL14995 | 1 | Spring | 08-11629 | $5.00 | |
| SL61247 | 1 | Cover, Rocker Box | 08-11788 | $32.84 | |
| SL74241A | 2 | Ring, Piston | 08-11934 | $52.64 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
Documents
- Technical Specifications (PDF)
Reviews
good value
Verified Purchase
Superior MS13997-3 Key
I’m happy!
Verified Purchase
Superior Exh Studs For Lycoming 0320 & 0290
Verified Purchase
Superior Exh Studs For Lycoming 0320 & 0290
Verified Purchase
Superior Lycoming Cylinder Base Seal 7
These are far superior to the Lycoming gaskets. They last longer, arent brittle and maintain there form better.
Verified Purchase
Superior SL71973 Gasket
Work as described
Verified Purchase
Superior MS49005-2 Plug
Parts are an identical match and fit.
Verified Purchase
Superior SL12272 Lock Plate
Shafts fit perfect on a 49 year old motor. Will be awesome when we fire it up.
Verified Purchase
Superior SL13790A Shaft, Rocker Valve
Verified Purchase
Superior MS13998-3 Cap
Verified Purchase
Superior SL71973 Gasket
