Millennium Cylinder Power Assembly Kit Contents SA47006L-A20P For: O-470-U; IO-470-D E F H L M N S U V
| Vendor Part Number | Quantity | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA630591 + | 1 | Insert | 08-11280 | $13.75 | |
| SA35967 + | 1 | Insert | 08-11002 | $36.85 | |
| 2-107 | 2 | Helicoil | 08-12035 | $4.95 | |
| SA401893 + | 4 | Stud | 08-03682 | $6.16 | |
| MS21209-C4-15 + | 2 | (12) Helicoil | 08-10818 | $1.28 | |
| SA47006S-A21P | 1 | Stud Assembly | 08-11062 | $1956.90 | |
| SA539988 | 1 | Valve, Intake | 08-11206 | $98.73 | |
| SA643873 | 1 | Valve, Exhaust | 08-03680 | $306.85 | |
| SA654441 | 2 | Spring-Valve Outer | 08-11489 | $10.45 | |
| SA654442 | 2 | Spring-Valve Inner | 08-11490 | $6.22 | |
| SA625393 | 2 | Valve Spring Retainer | 08-11213 | $1.59 | |
| SA629117-1 | 1 | Rotocoil | 08-11251 | $27.12 | |
| 646985 | 1 | Seal, Intake Guide | 08-11474 | $26.29 | |
| SA35971 | 1 | Retainer | 08-11004 | $19.25 | |
| SA652984 | 2 | Shaft, Rocker | 08-11488 | $23.93 | |
| SA652947 | 2 | Washer | 08-11487 | $0.67 | |
| MS90725-12 | 2 | Bolt, Rocker | 08-10874 | $0.88 | |
| SA625615 | 1 | Cover, Rocker Box | 08-11214 | $46.75 | |
| SA535118 | 8 | Screw, Rocker Box | 08-11173 | $1.59 | |
| AN960-4L | - | Washer | AN960-416L | $0.06 | |
MS35338-44 | 8 | Washer | MS35338-44 | $0.06 | |
| SA4003 | 2 | Ring | 08-11042 | $58.03 | |
| SA4705 | 1 | Ring | 08-11070 | $37.95 | |
| SA4709 | 1 | Ring | 08-11077 | $19.31 | |
| SA532200 | 1 | Gasket, Molded Rubber | 08-03683 | $3.91 | |
| SA534610 | 4 | Seal | 08-03679 | $1.49 | |
| SA534857 | 1 | Gasket | 08-11165 | $9.74 | |
| SA536413 | 1 | Gasket | 08-03684 | $0.83 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
