Continental At Overhaul Parts Replacement List - IO-520 B Ba C M Permold
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA646550-A1 | 1 | Major Overhaul Gasket Set (No Intake Hoses) | 08-11450 | $246.34 | |
| SA646551-A1 | 1 | Supplemental Gasket Set (IO-520-B) | 08-11451 | $24.75 | |
| SA632429-A3 | 1 | Major Overhaul Gasket Set | 08-11326 | $425.70 | |
| SA632430-A3 | 1 | Major Overhaul Gasket Set W/ Hoses (IO-520-C,M) | 08-11327 | $468.60 | |
| SA642917-1 | 10 | Intake Hoses | 08-11414 | $28.21 | |
| SA628488 | 6 | Hydraulic Valve Lifter | 08-11241 | $153.84 | |
| SA646277 | 6 | Hydraulic Valve Lifter Exhaust | 08-11432 | $150.59 | |
| SA646593-A1 | 1 | Main Bearing Set (Phase 3 and 3 Case) | 08-11465 | $521.40 | |
| SA520129 | 12 | Rocker Arm Bushing (One Piece Bushing) | 08-11102 | $9.85 | |
| SA530658 | 6 | Connecting Rod Bushing | 08-11142 | $12.04 | |
| SA643626-101 | 4 | Counterweight Pin (IO-520-B,C,M) | 08-11418 | $14.85 | |
| SA643626-104 | 2 | Counterweight Pin | 08-11421 | $14.85 | |
| SA643626-103 | 2 | Counterweight Pin | 08-11420 | $14.85 | |
| SA350998 | 16 | Counterweight Bushing | 08-10986 | $11.88 | |
| SA643629 | 16 | Counterweight Retaining Plates | 08-11424 | $1.87 | |
| SA629104 | 16 | Counterweight Snap Rings | 08-11249 | $0.72 | |
SA628109 | 12 | Connecting Rod Nuts | SA628109 | $6.33 | |
MS24665-229 | |||||
| SA631088-44 | 4 | Camshaft Bolts | 08-11299 | $5.88 | |
| SA536379 | 6 | Crankshaft Bolts | 08-11182 | $8.75 | |
| SA649205 | 4 | Crankshaft Alternator Face Gear Bolts | 08-11475 | $7.54 | |
| SA641909 | 2 | Crankshaft Alternator Face Gear Lock Plate | 08-11397 | $7.15 | |
| MS35756-8 | 2 | Woodruff Keys | 08-10859 | $1.32 | |
| SA638172 | 4 | Magneto Drive Rubber Bushings | 08-00321 | $5.00 | |
| SA643873 | 6 | Exhaust Valves | 08-03680 | $306.85 | |
| SA629117-1 | 6 | Exhaust Valve Rotocoils | 08-11251 | $27.12 | |
| SA654442 | 12 | Valve Springs - Outer | 08-11490 | $6.22 | |
| SA654441 | 6 | Valve Springs - Inner | 08-11489 | $10.45 | |
| SA630046 | 6 | Piston Pins | 08-11261 | $105.22 | |
| SA5000-SC5 | 6 | Piston Rings (For Steel Barrel) | 08-11084 | $161.43 | |
| SA652984 | 12 | Rocker Shafts | 08-11488 | $23.93 | |
| SA652947 | 12 | Rocker Shaft Retaining Bolt Washer | 08-11487 | $0.72 | |
| MS90725-12 | 12 | Rocker Shaft Retaining Bolt | 08-10874 | $0.88 | |
| SA641931-10.75 | 8 | Crankcase Through Bolt | 08-11398 | $84.53 | |
| SA531001 | 36 | Cylinder Hold Down Nuts | 08-11148 | $10.89 | |
| SA634505 | 12 | Cylinder Hold Down Nuts | 08-11353 | $10.95 | |
| SA641250 | 1 | Crankcase Nose Seal | 08-03675 | $59.35 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
| Continental engines are the culmination of hundreds of parts improvements made over the last six decades. |
