Continental At Overhaul Parts Replacement List - TSIO-360-A B C D E F G H
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA631348-A3 | 1 | Major Overhaul Gasket Set (Inc. Intake Hoses) | 08-11300 | $360.80 | |
| SA646543-A1 | 1 | Major Overhaul Gasket Set (Inc. Intake Hoses) | 08-11443 | $192.23 | |
| 642917-2 | 6 | Intake Hose | 08-11415 | $26.13 | |
| SA633106 | 12 | Hydraulic Valve Lifter | 08-11336 | $148.34 | |
| SA646597-A1 | 1 | Main Bearing Set | 08-11469 | $1084.60 | |
| SA627693 | 24 | Rocker Arm Bushing | 08-11232 | $2.92 | |
| SA538684 | 6 | Connecting Rod Bushing | 08-11200 | $15.95 | |
| SA639580 | 4 | Counterweight Pin | 08-11379 | $18.15 | |
| SA629004 | 8 | Counterweight Snap Rings | 08-11247 | $0.59 | |
| SA626140 | 12 | Connecting Rod Nuts | 08-11220 | $6.55 | |
MS24665-227 | 12 | Connecting Rod Cotter Pins | MS24665-227 | $0.18 | |
| SA630742 | 4 | Camshaft Bolts | 08-11286 | $9.74 | |
| SA630692 | 4 | Crankshaft Bolts | 08-11285 | $10.95 | |
| MS35756-8 | 1 | Woodruff Keys | 08-10859 | $1.32 | |
| SA638172 | 4 | Magneto Drive Rubber Bushings | 08-00321 | $5.00 | |
| SA646460 | 6 | Exhaust Valves | 08-11436 | $365.20 | |
| SA631654 | 12 | Exhaust Valve Rotocoils | 08-11309 | $45.65 | |
| SA627731 | 24 | Valve Keepers | 08-11233 | $3.58 | |
| SA625958 | 24 | Valve Springs | 08-11216 | $9.35 | |
| SA625957 | 24 | Valve Springs | 08-11215 | $5.88 | |
| SA629690 | 6 | Piston Pins | 08-11259 | $102.03 | |
| SA3610-SC | 6 | Piston Rings (For Steel Barrel) | 08-11013 | $197.73 | |
| SA631991 | 12 | Rocker Shafts | 08-11316 | $42.35 | |
| SA501867 | 12 | Rocker Shaft Retaining Bolt Washer | 08-11096 | $2.15 | |
| SA531001 | 12 | Cylinder Hold Down Nuts | 08-11148 | $10.89 | |
| SA531003 | 36 | Cylinder Hold Down Nuts | 08-11149 | $7.43 | |
| SA530917 | 1 | Crankcase Nose Seal | 08-11146 | $43.45 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
| Continental engines are the culmination of hundreds of parts improvements made over the last six decades. |
Documents
Reviews
Cheaper than TCM and likely made by same people. Always replace.
Verified Purchase
Superior SA531003 Nut
Verified Purchase
Superior SA3610-Sc Ring Set Single Cylinder
Great nut.
Verified Purchase
Superior SA531001 Nut, Cylinder Hold Down
Verified Purchase
Superior SA501867 Washer, Tab Lock
Verified Purchase
Cotter Pin Cor AN381-25-8
Verified Purchase
Superior SA531001 Nut, Cylinder Hold Down
In stock, arrived promptly and well packaged. No issues noted during installation..
Verified Purchase
Superior SA531001 Nut, Cylinder Hold Down
Verified Purchase
Superior SA626140 Nut
Verified Purchase
Superior SA530917 Seal Assembly Oil Crankshaft
Verified Purchase
Superior SA630692 Bolt
