Continental At Overhaul Parts Replacement List - TSIO-360 - Ab Cb Db Eb Fb Hb Jb Kb Lb Mb
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA631348-A3 | 1 | Major Overhaul Gasket Set (Inc. Intake Hoses) | 08-11300 | $360.80 | |
| SA646543-A1 | 1 | Major Overhaul Gasket Set | 08-11443 | $192.23 | |
| 642917-2 | 6 | Intake Hose | 08-11415 | $26.13 | |
| SA633106 | 12 | Hydraulic Valve Lifter | 08-11336 | $148.34 | |
| SA646597-A1 | 1 | Main Bearing Set | 08-11469 | $1084.60 | |
| SA627693 | 24 | Rocker Arm Bushing | 08-11232 | $2.92 | |
| SA538684 | 6 | Connecting Rod Bushing | 08-11200 | $15.95 | |
| SA639580 | 4 | Counterweight Pin | 08-11379 | $18.15 | |
| SA629004 | 8 | Counterweight Snap Rings | 08-11247 | $0.59 | |
| SA626140 | 12 | Connecting Rod Nuts | 08-11220 | $6.55 | |
MS24665-227 | 12 | Connecting Rod Cotter Pins | MS24665-227 | $0.18 | |
| SA630742 | 4 | Camshaft Bolts | 08-11286 | $9.74 | |
| SA630692 | 4 | Crankshaft Bolts | 08-11285 | $10.95 | |
| MS35756-8 | 1 | Woodruff Keys | 08-10859 | $1.32 | |
| SA638172 | 4 | Magneto Drive Rubber Bushings | 08-00321 | $5.00 | |
| SA646460 | 6 | Exhaust Valves | 08-11436 | $365.20 | |
| SA631654 | 12 | Exhaust Valve Rotocoils | 08-11309 | $45.65 | |
| SA627731 | 24 | Valve Keepers | 08-11233 | $3.58 | |
| SA625958 | 24 | Valve Springs | 08-11216 | $9.35 | |
| SA625957 | 24 | Valve Springs | 08-11215 | $5.88 | |
| SA629690 | 6 | Piston Pins | 08-11259 | $102.03 | |
| SA3610-SC | 6 | Piston Rings (For Steel Barrel) | 08-11013 | $197.73 | |
| SA631991 | 12 | Rocker Shafts | 08-11316 | $42.35 | |
| SA501867 | 12 | Rocker Shaft Retaining Bolt Washer | 08-11096 | $2.15 | |
| SA531001 | 12 | Cylinder Hold Down Nuts | 08-11148 | $10.89 | |
| SA531003 | 36 | Cylinder Hold Down Nuts | 08-11149 | $7.43 | |
| SA530917 | 1 | Crankcase Nose Seal | 08-11146 | $43.45 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
| Continental engines are the culmination of hundreds of parts improvements made over the last six decades. |
