Millennium Cylinder Power Assembly Kit Contents SA52006-A23P For: IO-550-A B C
| Vendor Part Number | Quantity Required | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SA35967 + | 1 | Insert | 08-11002 | $36.85 | |
| SA642318 + | 1 | Valve Seat Insert | 08-11402 | $38.49 | |
| MS21209-C4-15 + | 2 | (12) Helicoil | 08-10818 | $1.28 | |
| SA640482 + | 4 | Stud | 08-11387 | $25.96 | |
| SA52006-A23P | 1 | Stud Assembly | 08-11100 | $2172.50 | |
| MS9018-01/2-50 + | 2 | Helicoil | 08-10870 | $4.24 | |
| SA35971 | 1 | Retainer | 08-11004 | $19.25 | |
| SA539988 | 1 | Valve, Intake | 08-11206 | $98.73 | |
| SA625393 | 2 | Valve Spring Retainer | 08-11213 | $1.59 | |
| SA629117-1 | 1 | Rotocoil | 08-11251 | $27.12 | |
| SA654441 | 2 | Spring-Valve Outer | 08-11489 | $10.45 | |
| SA654442 | 2 | Spring-Valve Inner | 08-11490 | $6.22 | |
| SA643873 | 1 | Valve, Exhaust | 08-03680 | $306.85 | |
| 646985 | 1 | Seal, Intake Guide | 08-11474 | $26.29 | |
| MS90725-12 | 2 | Bolt, Rocker | 08-10874 | $0.88 | |
| SA652947 | 2 | Washer | 08-11487 | $0.67 | |
| SA652984 | 2 | Shaft, Rocker | 08-11488 | $23.93 | |
| SA625615 | 1 | Cover, Rocker Box | 08-11214 | $46.75 | |
| SA535118 | 8 | Screw, Rocker Box | 08-11173 | $1.59 | |
MS35338-44 | 8 | Washer | MS35338-44 | $0.06 | |
AN960-416L | 8 | Washer | AN960-416L | $0.06 | |
| SA5003A | 1 | Ring | 08-03679 | $1.49 | |
| SA5004 | 1 | Ring, Piston | 08-11093 | $37.95 | |
| SA5208 | 1 | Ring, Piston | 08-11106 | $69.03 | |
| SA5209 | 1 | Ring, Piston | 08-11110 | $22.55 | |
| RG-534857 | - | Valve Cover Gasket | 08-01317 | $12.93 | |
| SA536413 | 1 | Gasket | 08-03684 | $0.83 | |
| SA641066 | 1 | Packing | 08-03689 | $9.35 | |
| SA628260 | 1 | Gasket - 4 Pack | 08-17251 | $40.65 |
- JUMP TO
- Overview
- Documents
- Reviews
- Q&A
- View in Catalog
Overview
|
Uniform hardness all the way through the steel barrel walls which allows the barrel to provide even wear while withstanding extreme cylinder temperatures and pressures. Exhaust and intake ports are volumetrically matched to maximum output and performance. Increased port wall thickness - eliminates problems with warping and cracking. Computer-generated head fin configuration - deliver more uniform heat transfer and fewer "hot" spots. Manufactured from the most advanced alloys available - exceed industry standard for strength and porosity. + Included with stud assembly. |
