Mitchell D1-112-5240 Rotax 912 Tachometer

$416.90/Each
Price Includes GST
Quantity
Add to Wishlist
Part# 10-02744
MFR Model# D1-112-5240

Overview

Mitchell 2-1/4 Inch Mechanical Recording
FAA-TSO Approved

D1-112-5240 Special-Rotax 912


Calibrated to function to the Rotax 1.760 gearbox and indicates propeller RPM, not engine RPM.

Specifications

  • Instrument Size: 2-1/4”
  • Dial Range: 300 – 3300 RPM
  • Weight: 11 Oz.
  • Accuracy: +/- 25 RPM, 1000 – 3000 RPM
  • Depth: 3-3/4”
  • Approval: TSO C49b
  • Warranty: 2 years Factory Direct

Documents

Reviews

Q&A

Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Does this Mitchell D1-112-5240 Rotax tachometer come with the green, yellow and red markings painted on as illustrated?

Yes, the tachometer looks exactly as shown in the photo.

Q: Is there a wiring diagram for this Mitchell D1-112-5240 tach?

Please view the Documents tab for installation instructions to this gauge.
