Whelen HS5 Installation Package 5

$71.23/Each
Price Includes GST
Part# 11-04204
MFR Model# 01-0750215-00

Overview

Designed to produce light 360° around the aircraft ±30° as required. Mount on top or bottom of fuselage or on vertical fin. Requires use of either H 102 or H 103 mounting adapters. Special three conductor shielded cable must be used between light assembly and power supply.

MODEL A 470A
Incorporates vibration proof flash tube (A 469B) which allows flush mounting. Available with Aviation Red, White or split Red/White optic lens. Specify voltage.

MODEL A 450
White strobe light with clear Pyrex glass dome. recommended for installations subject to severe vibration, moisture and chemical conditions such as Ag aircraft. This system was designed in 1968 when only 100 candles output was required. An economical system for daylight operation. Specify voltage.
  • Frequently Purchased With
  • Customers Also Viewed

Reviews

Q&A

Please note, Aircraft Spruce Australia's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician. Aircraft Spruce Australia assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.

Q: Regarding this cable kit, does it come with only one cable that's up to 30 feet long or is it a set of cables (3)? Thanks

It is one cable.

Q: When installing the A450 light assembly what adapter do I require? I am replacing a Whelen Model 70509,

The H102 adapter is used for flush mounting, and the H103 is used for mounting in a standard 3-3/4" rotating beacon hole.

Q: Is the Whelen A450 light FAA-PMA or STC approved?

Yes, this is PMA approved.

Q: Does the A470ADS Whelen strobe require a separate power pack or can it be wired direct to the 12 v aircraft bus bar?

It would require a power supply.

Q: Does the Whelen install kit come with the pins and connectors?

Yes the connectors and pins are included.

Q: Is this cable 01-0750215-00 FAA-PMA approved?

Cable 01-0750215-00 does not have any FAA approvals.

Q: i require cabling to suit vans rv9a. do you supply 15ft cabling kit for each wing and one kit to rudder strobe or do i just order the 60 ft cabling kit?

We do not have 15 ft kits. You would need to just order the kit closest to the total number of feet you need.
